Weight Rating Chart

Work out your Front & Rear Weight

Simply add up your accessories to work out your Front & Rear Weight Rating*

Average Front Weight by Accessory

Front Accessory Average Weight Average Range
Plastic Factory Bumper 0 0
Alloy Bull Bar 35kg 20 - 40kg
Steel Bull Bar Light 52kg 45 - 60kg
Steel Bull Bar HD 69kg 65 - 77kg
Winch with Rope 28kg 20 - 36kg
Winch with Cable 35kg 29 - 40kg
Dual Battery 22kg 16 - 28kg
Rock Sliders 52kg 35 - 60kg
Alloy Bash / Skid Plates 14kg 9 - 20kg
Steel Bash / Skid Plates 23kg 13 - 40kg
Brush Bars 7kg 5 - 10kg



Front Weight Rating

Front Weight Rating Weight (kg)
Light 0kg - 50kg
Medium 50kg - 100kg
Heavy 100kg - 250kg



Average Rear Weight by Accessory

Rear Accessory Average Weight (kg) Average Range (kg)
Factory Tub 0kg 0kg
Alloy Tray Standard Length 150kg 150kg - 200kg
Steel Tray Standard Length 272kg 265kg - 300kg
Tool Box One Side Loaded 85kg 70kg - 100kg
Tool Box Two Sides Loaded 170kg 140kg - 200kg
Dog Box 90kg 60kg - 150kg
Canopy 233kg 200kg - 300kg
Rear Bar 57kg 40kg - 80kg
Long Range Fuel Tank Loaded 200kg 190kg - 220kg
Drawers Unloaded 81kg 60kg - 114kg
Fridge Drop Slide 44kg 40kg - 50kg
Fridge 24kg 20kg - 29kg
Steel Wheels Beadlock Imitations 18kg 17kg - 19kg
31" Tyres 22kg 22kg
35" Tyres 30kg 30kg



Rear Weight Rating

Rear Weight Rating Weight Range (kg)
Extra Light Duty 0kg - 100kg
Light Duty 100kg - 300kg
Medium Duty 300kg - 500kg
Heavy Duty 500kg - 600kg
Extra Heavy Duty 600kg +
Mining Spec Mining Spec



*DISCLAIMER - Weights, Average Weights and Ranges are given as a rough guide only as each vehicle can vary. Don't hesitate to contact us if you need help.
