Weight Rating Chart
Work out your Front & Rear Weight
Simply add up your accessories to work out your Front & Rear Weight Rating*
Average Front Weight by Accessory
| Front Accessory | Average Weight | Average Range |
|---|---|---|
| Plastic Factory Bumper | 0 | 0 |
| Alloy Bull Bar | 35kg | 20 - 40kg |
| Steel Bull Bar Light | 52kg | 45 - 60kg |
| Steel Bull Bar HD | 69kg | 65 - 77kg |
| Winch with Rope | 28kg | 20 - 36kg |
| Winch with Cable | 35kg | 29 - 40kg |
| Dual Battery | 22kg | 16 - 28kg |
| Rock Sliders | 52kg | 35 - 60kg |
| Alloy Bash / Skid Plates | 14kg | 9 - 20kg |
| Steel Bash / Skid Plates | 23kg | 13 - 40kg |
| Brush Bars | 7kg | 5 - 10kg |
Front Weight Rating
| Front Weight Rating | Weight (kg) |
|---|---|
| Light | 0kg - 50kg |
| Medium | 50kg - 100kg |
| Heavy | 100kg - 250kg |
Average Rear Weight by Accessory
| Rear Accessory | Average Weight (kg) | Average Range (kg) |
|---|---|---|
| Factory Tub | 0kg | 0kg |
| Alloy Tray Standard Length | 150kg | 150kg - 200kg |
| Steel Tray Standard Length | 272kg | 265kg - 300kg |
| Tool Box One Side Loaded | 85kg | 70kg - 100kg |
| Tool Box Two Sides Loaded | 170kg | 140kg - 200kg |
| Dog Box | 90kg | 60kg - 150kg |
| Canopy | 233kg | 200kg - 300kg |
| Rear Bar | 57kg | 40kg - 80kg |
| Long Range Fuel Tank Loaded | 200kg | 190kg - 220kg |
| Drawers Unloaded | 81kg | 60kg - 114kg |
| Fridge Drop Slide | 44kg | 40kg - 50kg |
| Fridge | 24kg | 20kg - 29kg |
| Steel Wheels Beadlock Imitations | 18kg | 17kg - 19kg |
| 31" Tyres | 22kg | 22kg |
| 35" Tyres | 30kg | 30kg |
Rear Weight Rating
| Rear Weight Rating | Weight Range (kg) |
|---|---|
| Extra Light Duty | 0kg - 100kg |
| Light Duty | 100kg - 300kg |
| Medium Duty | 300kg - 500kg |
| Heavy Duty | 500kg - 600kg |
| Extra Heavy Duty | 600kg + |
| Mining Spec | Mining Spec |
*DISCLAIMER - Weights, Average Weights and Ranges are given as a rough guide only as each vehicle can vary. Don't hesitate to contact us if you need help.
